6000-12000GS Magnetic Liquid Filter SS304 SS316 Permanent Magnet Separator
-
High Light
12000GS Magnetic Liquid Filter
,6000GS Magnetic Liquid Filter
,SS316 Permanent Magnet Separator
-
Product NameMagnetic Liquid Filter
-
OriginHebei China
-
Applicable IndustriesPlastics, Food, Environmental Protection, Filtration, Chemicals, Electric Power, Building Materials, Ceramics, Medicine, Powder, Mining, Coal, Etc.
-
Warranty ServiceVideo Technical Support, Online Support Maintenance And Repair Services
-
Material304/316
-
TypeEverlasting
-
Inlet/outlet DiameterDN100
-
Peak Magnetic Field6000-12000GS
-
Maximum Temperature0-120 Degrees Celsius
-
Design Pressure (Mpa)2.5
-
Place of OriginHeBei China
-
Brand NameJing shark
-
Minimum Order Quantity1 set of
-
PriceNegotiable
-
Packaging DetailsSpecial carton and wooden case packing for export
-
Delivery Time15 days
-
Payment TermsT/T
-
Supply Ability10,000 units per month
6000-12000GS Magnetic Liquid Filter SS304 SS316 Permanent Magnet Separator
Permanent magnet separator
Describe
The magnetic separator is used in fluids, semi-fluids and other fluid materials with different viscosities to remove iron impurities and other ferromagnetic particles, keep the materials clean, and at the same time play a role in protecting downstream production equipment.
Working principle:
In the liquid transportation process, when the liquid passes through the filter, it is subjected to the magnetic action of the strong magnetic rod, and the iron impurities in the slurry are adsorbed on the magnetic rod sleeve, which greatly reduces the iron impurities in the slurry and ensures the next process Can effectively control the iron impurity content.
| Product name | Magnetic liquid filter |
| Model: | JSYL-CC |
| Specification: |
DN32~300
|
| Shell material: | 304 304L 316 316L |
| Sealing gasket: | Nitrile rubber, PTFE, metal gasket |
| Ambient temperature: | 0°C to 120°C |
| Nut bolt: | 304 304L 316 316L |
| Connection mode: | Flange connection threaded connection |
| Working pressure: | 0.1-2.5MPA |
Application range:
Used in food and beverage, metal processing, pharmaceuticals, ceramics, paper, cosmetics, fine chemicals and other industries to protect key equipment from iron particles.
