Hand Crank Automatic Low Pressure Water Filter Self Cleaning Sediment Filter

Hand crank automatic multi-core backwash filter

Product Description

The positioning plate and the cleaning swing arm are mounted on a shaft driven by a gear motor. Each positioning hole on the disc matches each screen, and the cleaning arm corresponds to one hole. When a hole reaches the positioning sensor channel, the sensor outputs a signal to stop the gear motor. The cleaning arm aimed at one element at the same time. Cleaning The valve opens for a few seconds until the filter element is cleaned. Then the gear motor continues to rotate. When the next hole on the disc reaches the sensor channel, the gear motor will stop and clean the next screen.

Advantage

1. The filter element recoils, after aligning the filter element, open the drain valve to recoil, the backwashing intensity is high, the effect is good, the time-consuming is short, and the liquid is saved

2. The automatic control system has high reliability; the interface is intuitive and easy to operate efficiently according to actual working conditions.
3. Water enters at both ends of the filter to increase the flux of the filter cartridge; the free flow of water can delay the surface blockage and avoid the blockage of one end of the filter;

4. Compact design, large flux, greatly saving installation space and construction cost;

Applicable industry

Applicable liquid types: ground water, sea water, lake water, reservoir water, pond water, circulating cooling water, chilled water, high and low pressure spray water, water needle water, heat exchange water, sealing water, bearing cooling water, oil well water injection, process circulating water , Machining coolant, cleaning agent, cleaning water, etc.
